NEC Versa 6000 Series
The NEC Versa 6000 Series were Pentium MMX-based laptops that were released in 1996. See below for specifications.
Specifications
| Spec | Versa 6000H | Versa 6030H | Versa 6030X | Versa 6050MH | Versa 6050MX |
|---|---|---|---|---|---|
| CPU | CPU Type: Soldered TCP Intel Pentium @100MHz | CPU Type: Soldered TCP Intel Pentium @133MHz | CPU Type: Soldered TCP Intel Pentium MMX @150MHz | ||
| Chipset | Intel 430MX | ||||
| RAM | Type: Unknown Standard: 16MB Soldered Maximum: Unknown | ||||
| Storage | 2.5" IDE Requires Adapter: Unknown Standard: 1.08GB | 2.5" IDE Requires Adapter: Unknown Standard: 1.35GB | 2.5" IDE Requires Adapter: Unknown Standard: 1.44GB | 2.5" IDE Requires Adapter: Unknown Standard: 2.1GB | |
| Display Options | 11.3" Active Matrix LCD @800x600 | 12.1" Active Matrix LCD @800x600 | 12.1" Active Matrix LCD @1024x768 | 12.1" Active Matrix LCD @800x600 | 12.1" Active Matrix LCD @1024x768 |
| Graphics Chipset | Chips & Technologies 65550 VRAM: 2MB | ||||
| Audio | Creative Labs ViBRA 16S (CT2504) | Creative Labs ViBRA 16C (CT2505) | |||
| Main Battery | Lithium Ion (14.4V, 2600mAH) | ||||
| CMOS Battery | - Lithium Ion (3V, 280mAH) CMOS Battery - 6V 60mAH Bridge Battery (probably NiMH) | ||||
| Power Supply | Proprietary 3-pin | ||||
| Media Drives | VersaBay II - holds CD-ROM, Floppy Drive, 2nd HDD, or 2nd Battery | ||||
| PC Cards | 2x PCMCIA/CardBus Slots | ||||
| Networking | Modem | ||||
| Other I/O | - 1x Parallel - 1x Serial - 1x VGA Out - 1x PS/2 - 1x Dock Connector - 1x Mic In - 1x Line In - 1x Line Out - 1x Headphone Out - Infrared | ||||
| BIOS | Phoenix | ||||
| Pointing Device | Trackpad | ||||
Resources
Service Manual (6000H, 6030H, 6030X)
Service Manual (6050MH, 6050MX)
Page last updated (MM/DD/YYYY): 03/09/2025
Update Reason: page converted to php
